Specifications
| Model | CA6DL1-31 | CA6DL1-28 | CA6DL1-26 |
| Type | 6-cylinder in-line, direct injection, turbocharged&intercooling | ||
| Bore× Stroke (mm ×mm) | 110×125 | ||
| Valve number | 4 | ||
| Total displacement (L) | 7.7 | ||
| Rated power/speed (kW/r/min) | 239/2300 | 209/2300 | 203/2300 |
| Net power/speed (kW/r/min) | 228/2300 | 206/2300 | 192/2300 |
| Max torque/speed (N. m /r/min) | 1100/1300～1500 | 1100/1300～1500 | 1000/1300～1500 |
| Min. fuel consumption at full load (g/kW. h ) | 195 | ||
| Technical Route | Fuel Mechanical Pump | ||
| Emission Compliant (TAS) | National II | ||
