Specifications
| Model | CA6DL1-32E5 | CA6DL1-29E5 | CA6DL1-28E5 | CA6DL1-26E5 |
| Type | 6-cylinder in-line, direct injection, turbocharged&intercooling, common rail | |||
| Bore× Stroke (mm ×mm) | 110×135 | |||
| Valve number | 4 | |||
| Total displacement (L) | 7.7 | |||
| Rated power/speed (kW/r/min) | 238/2300 | 216/2300 | 209/2300 | 195/2300 |
| Net power/speed (kW/r/min) | 235/2300 | 213/2300 | 206/2300 | 192/2300 |
| Max torque/speed (N. m /r/min) | 1250/1300～1600 | 1150/1300～1600 | 1100/1300～1600 | 1050/1300～1600 |
| Min. fuel consumption at full load (g/kW. h ) | 192 | |||
| Technical Route | SCR+BOSCH electronic control system | |||
| Emission Compliant (TAS) | National V (obtained e/E Euro V certification) | |||
Globally Leading Intelligent Power Solutions
We have delivered over 280,000 high-performance engines to 67 countries and regions worldwide. Explore intelligent manufacturing and reliable power to create greater value for your business.
