Self-developed Common Rail + Elimination of Post-treatment

Inquiry Now

Specifications

Model	CA6DM3-46	CA6DM3-55E		CA6DM3-52E	CA6DM3-56E
Type	6-cylinder in-line, direct injection, turbocharged&intercooling, common rail
Bore× Stroke (mm ×mm)	126.5×166
Valve number	4
Total displacement (L)	12.52
Rated power/speed (kW/r/min)	341/1800		407/1800	386/1800	415/1800
Net power/speed (kW/r/min)	338/1800		404/1800	383/1800	412/1800
Max torque/speed (N. m /r/min)	2200/1100～1400		2300/1100～1300	2500/1100～1400	2600/1100～1400
Min. fuel consumption at full load (g/kW. h )	186
Technical Route	National Five SCR independent common rail + cancellation of after-treatment			National VI SCR independent common rail + cancellation of post-treatment
Emission Compliant (TAS)	Country 2		No emission requirements
